Toro Groundsmaster 4500-D Series User Manual

OperatorSeatSuspension
FRONT
RIGHT
11
8
7
30
10
15
6
12
13
5
3
4
2
1
9
21
33
16
17
18
19
20
22
23
24
25
26
27
28
29
31
32
33
34
35
36
14
37
38
39
g276887
Figure295
1.Cover14.Washer(2used)27.Clamp(2used)
2.Cover
15.T ether28.Hosenipple
3.Levelcontrol
16.Rivet(2used)29.Screw
4.Aircontrolvalve
17.Washer(4used)
30.Handle
5.Shockabsorber18.C−clip(4used)
31.Bumper
6.Airspring
19.Pin(2used)
32.Nut
7.Airtubeassembly
20.Rivet(2used)33.Plasticplug(23used)
8.Wireharness
21.Washer(3used)34.Screw(2used)
9.Compressor22.Screw(2used)35.Roller(2used)
10.Bellows23.Washer
36.Screw(4used)
11.Stop24.Housingsupport(4used)
37.Baseplate
12.Bumperset(2used)25.Spacer(4used)38.Suspensionframe
13.Roller(4used)
26.Hosenipple39.Upperplate
Note:Mostoftheseatsuspensioncomponentscanbeservicedwiththeseat
suspensionbasemountedtotheseatplate.Iftheairspringassembly(item6)
requiresremoval,theseatsuspensionbasewillhavetoberemovedfromthe
seatplate.
Groundsmaster
®
4500-D/4700-D
Page8–23
Chassis:ServiceandRepairs
19245SLRevA
