VA02SeriesPlanetaryDriveService
VA02 series planetary
11
12
13
14
15
1617
18
19
20
1
2
3
4
4
5
5
6
7
8
9
10
21
22
24
24
23
25
26
27
28
37 N·m (27 ft-lb)
g276546
Figure236
1.Spindle11.O−ring
21.Endcap
2.Bootseal
12.Spacer
22.Thrustplate
3.Lipseal13.Lockingwasher
23.O−Ring
4.Innerbearingcup(2)
14.Locknut
24.Retainingring(2)
5.Innerbearingcone(2)
15.Ringgear25.Primarygear
6.Wheelstud(8)
16.Retainingring
26.Driveshaft
7.Socketheadscrew(8)
17.Plug27.Primarycarrierassembly
8.Lockwasher(8)18.O−ring28.Secondarycarrierassembly
9.Housing
19.Plug(2)
10.Dowelpin(4)20.O−Ring(2)
Groundsmaster
®
4500-D/4700-D
Page7–11
Axles,PlanetariesandBrakes:ServiceandRepairs
19245SLRevA
