FanSpeedSwitch(MachineswithTwo−PostROPSExtension
OperatorFanKit)
1
2
3
g276047
Figure225
1.Fanspeedswitch
3.Controlpanel
2.Controlknob
Thefanspeedswitchisattachedtotheoverheadcontrolpanel(Figure225).The
switchisusedtoselectthefanspeed(off,low,medium,orhigh).
Testing
1.Parkthemachineonalevelsurface,lowerthecuttingdecks,andshutoff
theengine.Removethekeyfromthekeyswitch.
2.Toaccesstheswitch,removethesunshadefromthetopoftheROPS
extension.
3.Disconnectthemachinewireharnessfromthefanspeedswitch.
L
M
H
C
B
g276048
Figure226
Groundsmaster
®
4500-D/4700-D
Page6–65
ElectricalSystem:ComponentTesting
19245SLRevA
