RearAxleMotor
g308773
Figure111
1.Rearaxlemotor
7.O-ring13.O-ring
2.O-ring8.90ºhydraulictting14.O-ring
3.Piniongear
9.Capscrew(2used)15.90ºhydraulictting
4.Externalsnapring(2used)10.Flatwasher(2used)16.O-ring
5.O-ring11.O-ring17.T emperaturesenderwithO-ring
6.Hydraulictting12.90ºhydraulictting
Removal(Figure111)
1.Parkmachineonalevelsurface,lowercuttingdecks,stopengine,engage
parkingbrakeandremovekeyfromtheignitionswitch.
2.ReadtheGeneralPrecautionsforRemovingandInstallingHydraulicSystem
Components(page5–87).
3.Topreventcontaminationofhydraulicsystemduringrearaxlemotorremoval,
thoroughlycleanexteriorofmotor.
4.Disconnectwireharnessconnectorfromthetemperaturesender(item17)
ontherearaxlemotor.
5.Disconnecthydrauliclinesfrommotor.Putcapsorplugsonlinesandttings
topreventcontamination.Labelthehydraulichosestoshowtheircorrect
positionontheaxlemotorforassemblypurposes.
HydraulicSystem:ServiceandRepairs
Page5–116
Groundsmaster
®
4500-D/4700-D
19245SLRevA
