BevelGearCaseandAxleCase
Thefollowingproceduresassumetherearaxleassemblyhasbeenremoved
fromthemachine.
Removal
1
2
3
4
5
6
(35 to 41 ft-lb)
47 to 56 N·m
(35 to 41 ft-lb)
47 to 56 N·m
g276508
Figure245
1.Capscrew(4used)
4.Axlesupport
2.Locknut(2used)5.Bevelgearcase/axlecaseassembly
3.Lockwasher(2used)6.O-ring
1.Removethemountingscrews,nutsandlockwashers.Removethebevel
gearcase/axlecaseassemblyandO-ringfromtheaxlesupport(Figure245).
2.Markbothrightandleftbevelgearcase/axlecaseassemblies.
IMPORTANT
Donotinterchangerightandleftbevelgearcase/axlecase
assemblies.
1
2
3
4
(17 to 20 ft-lb)
23 to 27 N·m
g276510
Figure246
1.Axlecase
3.Screw(6used)
2.Axlecoverassembly
4.O-ring
3.Removetheaxlecovermountingscrews.Removetheaxlecoverfromthe
axlecaseasanassembly(Figure246).
Axles,PlanetariesandBrakes:ServiceandRepairs
Page7–22
Groundsmaster
®
4500-D/4700-D
19245SLRevA
