4-REAR WHELL COMPONENT 19
CHK
ADJ
NO. PART NO.
1 1251100-085093 Non－standard bolt M10×1.5×75(dacromet) 1
2 1251100-132003 Non－standard bolt M10×1.5×80(dacromet) 1
3 Rear shock absorption 1
4
1251300-057093 Non－standard nut M10×1.5(dacromet) 2 65±2N.m
PROCEDURE:
●Rear shock absorber
Put down side stand. Person 1: Turn the handling bar to left end with left hand; hold tight the rear pedal with
right hand and lean the motorcycle to left side.Another person used a wooden stool to put a soft rubber cushion
on the right side muffler back pressure bag of the bike to support the whole bike and let the rear wheel slightly
off the ground.
After supporting the whole bike, use a 14# wrench to fix the nut ⑷ at the bottom of the shock absorber. One
person uses a 14# sleeve on the right to loosen the bolt ⑵ counterclockwise and remove the nut ⑷.
Person 1 shake slightly the rear wheel up and down. Person 2 drag out bolt⑵.
Person 1 fix the head of the bolt⑴ with a 14# sleeve,person 2 remove the nut ⑷ with a 14# sleeve.Lift the rear
shock absorber⑶ towards the arrow direction and drag out bolt⑴. Take off the rear absorber at last.
●Adjust the rear absorber
Using hook spanner to loosen adjustive nut①. Rotate adjustive nut②. If the nut is rotated towards the arrow
direction, the spring becomes harder. Conversly, the absorber is softer. Tighten the adjustive nut① until the
absorber is under suitable status. Please adjust in a reasonable range. Riding experience would be influenced
either the absorber is too soft or too hard.
CAUTION:
●Disassemble seat, L,side cover, R, side cover, bolts on front parts of rear cover and rear inner mudguard.
●Using suitable tool to support the motorcycle. Avoid accidents caused by falling motorcycle. Single person
manipulation is prohibited.
●All the standard parts need to reach standard torque while reassembling.
Fig.2 REAR WHELL
COMPONENT
To Next Page
