Parameters 157
03.11 DDCS controller ref
1
Reference 1 received from the external (DDCS) controller.
The value has been scaled according to parameter 60.60
DDCS controller ref1 type.
See also section External controller interface (page 75).
1 = 10
-30000.00 …
30000.00
Scaled reference 1 received from external controller. 1 = 10
03.12 DDCS controller ref
2
Reference 2 received from the external (DDCS) controller.
The value has been scaled according to parameter 60.61
DDCS controller ref2 type.
1 = 10
-30000.00 …
30000.00
Scaled reference 2 received from external controller. 1 = 10
03.13 M/F or D2D ref1 Master/follower reference 1 received from the master. The
value has been scaled according to parameter 60.10 M/F ref1
type.
See also section Master/follower functionality (page 68).
1 = 10
-30000.00 …
30000.00
Scaled reference 1 received from master. 1 = 10
03.14 M/F or D2D ref2 Master/follower reference 2 received from the master. The
value has been scaled according to parameter 60.11 M/F ref2
type.
1 = 10
-30000.00 …
30000.00
Scaled reference 2 received from master. 1 = 10
04
04 Warnings and faults
Information on warnings and faults that occurred last.
For explanations of individual warning and fault codes, see
chapter Fault tracing.
All parameters in this group are read-only unless otherwise
noted.
04.01 Tripping fault Code of the 1st active fault (the fault that caused the current
trip).
-
0000h…FFFFh 1st active fault. 1 = 1
04.02 Active fault 2 Code of the 2nd active fault. -
0000h…FFFFh 2nd active fault. 1 = 1
04.03 Active fault 3 Code of the 3rd active fault. -
0000h…FFFFh 3rd active fault. 1 = 1
04.04 Active fault 4 Code of the 4th active fault. -
0000h…FFFFh 4th active fault. 1 = 1
04.05 Active fault 5 Code of the 5th active fault. -
0000h…FFFFh 5th active fault. 1 = 1
04.06 Active warning 1 Code of the 1st active warning. -
0000h…FFFFh 1st active warning. 1 = 1
04.07 Active warning 2 Code of the 2nd active warning. -
0000h…FFFFh 2nd active warning. 1 = 1
04.08 Active warning 3 Code of the 3rd active warning. -
0000h…FFFFh 3rd active warning. 1 = 1
04.09 Active warning 4 Code of the 4th active warning. -
0000h…FFFFh 4th active warning. 1 = 1
No. Name/Value Description Def/FbEq16
