ABB ACS880-04XT User Manual

554 Additional parameter data
81 Pump cleaning
81.01 Pump cleaning enable List ---
81.02 Pump cleaning option sel PB 0b0000…0b111111111111
1111
--
81.11 Manual trigger source List ---
81.19 Time trigger Real 0.00...650.00 hour 100 = 1hour
81.20 Number of cleaning cycles Real 0...65000 - 1 = 1
81.21 First step reference Real -300.00...300.00 % 100 = 1%
81.22 First step time Real 0.0...6500.0 s 10 = 1s
81.23 Off time Real 0...65000 s 1 = 1
81.24 Second step reference Real -300.00...300.00 % 100 = 1%
81.25 Second step time Real 0.0...6500.0 s 10 = 1s
81.31 Cleaning acc time Real 0.00...30000.00 s 100 = 1s
81.32 Cleaning dec time Real 0.00...30000.00 s 100 = 1s
81.35 Acceleration boost current Real 0.00...300.00 % 100 = 1%
81.40 Cleaning abort source List ---
81.41 Supervision low signal src List ---
81.42 Supervision low limit Real 0.00...30000.00 - 100 = 1
81.43 Supervision low delay Real 0.0...3200.0 s 10 = 1s
81.46 Supervision high signal src List ---
81.47 Supervision high limit Real 0.00...30000.00 - 100 = 1
81.48 Supervision high delay Real 0.0...3200.0 s 10 = 1s
81.51 Cleaning max event List ---
81.52 Clean max amount Real 0...100 - 1 = 1
81.53 Clean max period Real 0.00...650.00 hour 100 = 1hour
81.80 Cleaning reference % Real -1200.00...1200.00 % 100 = 1%
81.81 Since last cleaning Real 00 00:00...99 00:00 - -
81.82 Until next cleaning Real 00 00:00...99 00:00 - -
81.99 Cleaning status word PB 0b0000…0b111111111111
1111
--
85 Q-H pump curves
85.01 Pump curve input function List ---
85.02 Input 1 source List ---
85.03 Input 2 source List ---
85.04 Curve frequency 1 Real 0.00...600.00 Hz 100 = 1Hz
85.05 Curve frequency 2 Real 0.00...600.00 Hz 100 = 1Hz
85.06 Curve frequency 3 Real 0.00...600.00 Hz 100 = 1Hz
85.07 Curve frequency 4 Real 0.00...600.00 Hz 100 = 1Hz
85.08 Curve frequency 5 Real 0.00...600.00 - 100 = 1
85.09 Pump curve scale coef Real 0.000...30.000 - 1000 = 1
85.10 Head at 0 flowrate 1 Real 0.00...32000.00 - 100 = 1
85.11 Flowrate max 1 Real 0.00...32000.00 - 100 = 1
No. Name Type Range Unit FbEq32
