Parameters 231
16.83 AO1 out at AO1 src
max
(Visible when 16.01 Module 3 type = FIO-11 or FA IO-0 1)
See parameter 14.83 AO1 out at AO1 src max.
10.000 mA
16.86 AO2 actual value (Visible when 16.01 Module 3 type = FAIO-01)
See parameter 14.86 AO2 actual value.
-
16.87 AO2 source (Visible when 16.01 Module 3 type = FAIO-01)
See parameter 14.87 AO2 source.
Zero
16.88 AO2 force data (Visible when 16.01 Module 3 type = FAIO-01)
See parameter 14.88 AO2 force data.
0.000 mA
16.89 AO2 filter time (Visible when 16.01 Module 3 type = FAIO-01)
See parameter 14.89 AO2 filter time.
0.100 s
16.90 AO2 source min (Visible when 16.01 Module 3 type = FAIO-01)
See parameter 14.90 AO2 source min.
0.0
16.91 AO2 source max (Visible when 16.01 Module 3 type = FAIO-01)
See parameter 14.91 AO2 source max.
100.0
16.92 AO2 out at AO2 src
min
(Visible when 16.01 Module 3 type = FAIO-01)
See parameter 14.92 AO2 out at AO2 src min.
0.000 mA
16.93 AO2 out at AO2 src
max
(Visible when 16.01 Module 3 type = FAIO-01)
See parameter 14.93 AO2 out at AO2 src max.
10.000 mA
19
19 Operation mode
Selection of local and external control location sources and
operating modes.
See also section Operating modes of the drive (page 26).
19.01 Actual operation
mode
Displays the operating mode currently used.
See parameters 19.11…19.14.
This parameter is read-only.
-
Zero None. 1
Speed Speed control (in DTC motor control mode). 2
Torque Torque control (in DTC motor control mode). 3
Min The torque selector is comparing the output of the speed
controller (25.01 Torque reference speed control) and torque
reference (26.74 Torque ref ramp out) and the smaller of the
two is used.
4
Max The torque selector is comparing the output of the speed
controller (25.01 Torque reference speed control) and torque
reference (26.74 Torque ref ramp out) and the greater of the
two is used.
5
Add The speed controller output is added to the torque reference. 6
Scalar (Hz) Frequency control in scalar motor control mode. 10
Scalar (rpm) Speed control in scalar motor control mode. 11
Forced magn. Motor is in magnetizing mode. 20
19.11 Ext1/Ext2 selection Selects the source for external control location EXT1/EXT2
selection.
0 = EXT1
1 = EXT2
EXT1
EXT1 EXT1 (permanently selected). 0
EXT2 EXT2 (permanently selected). 1
FBA A MCW bit 11 Control word bit 11 received through fieldbus interface A. 2
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 3
No. Name/Value Description Def/FbEq16
