ABB ACS880-04XT User Manual

532 Additional parameter data
33.52 Value counter 1 function PB 00b…11b - 1 = 1
33.53 Value counter 1 source Analog
src
--1 = 1
33.54 Value counter 1 divider Real 0.001 … 2147483.000 - 1000 = 1
33.55 Value counter 1 warn message List --1 = 1
33.60 Value counter 2 actual Real -2147483008 …
2147483008
-1 = 1
33.61 Value counter 2 warn limit Real -2147483008 …
2147483008
-1 = 1
33.62 Value counter 2 function PB 00b…11b - 1 = 1
33.63 Value counter 2 source Analog
src
--1 = 1
33.64 Value counter 2 divider Real 0.001 … 2147483.000 - 1000 = 1
33.65 Value counter 2 warn message List --1 = 1
35 Motor thermal protection
35.01 Motor estimated temperature Real -60 … 1000 °C or °F 1 = 1°
35.02 Measured temperature 1 Real -60 … 1000 °C,
-76 … 1832 °F,
0…5000 ohm
°C, °F or
ohm
1 = 1 unit
35.03 Measured temperature 2 Real -60 … 1000 °C,
-76 … 1832 °F,
0…5000 ohm
°C, °F or
ohm
1 = 1 unit
35.04 FPTC status word PB 0000h…FFFFh - 1 = 1
35.11 Temperature 1 source List 0…11 - 1 = 1
35.12 Temperature 1 fault limit Real -60 … 1000 °C,
-76 … 1832 °F or
0…5000 ohm
°C, °F or
ohm
1 = 1 unit
35.13 Temperature 1 warning limit Real -60 … 1000 °C,
-76 … 1832 °F or
0…5000 ohm
°C, °F or
ohm
1 = 1 unit
35.14 Temperature 1 AI source Analog
src
--1 = 1
35.21 Temperature 2 source List 0…11 - 1 = 1
35.22 Temperature 2 fault limit Real -60 … 1000 °C,
-76 … 1832 °F or
0…5000 ohm
°C, °F or
ohm
1 = 1 unit
35.23 Temperature 2 warning limit Real -60 … 1000 °C,
-76 … 1832 °F or
0…5000 ohm
°C, °F or
ohm
1 = 1 unit
35.24 Temperature 2 AI source Analog
src
--1 = 1
35.30 FPTC configuration word PB 0000h…FFFFh - 1 = 1
35.50 Motor ambient temperature Real -60 … 100 °C or
-76 … 212 °F
°C or °F 1 = 1°
35.51 Motor load curve Real 50…150 % 1 = 1%
35.52 Zero speed load Real 50…150 % 1 = 1%
35.53 Break point Real 1.00 … 500.00 Hz 100 = 1 Hz
No. Name Type Range Unit FbEq32
