530 Additional parameter data
31.13 User selectable fault Real 0000h…FFFFh - 1 = 1
31.14 Number of trials Real 0…5 - 1 = 1
31.15 Total trials time Real 1.0 … 600.0 s 10 = 1 s
31.16 Delay time Real 0.0 … 120.0 s 10 = 1 s
31.19 Motor phase loss List 0…1 - 1 = 1
31.20 Earth fault List 0…2 - 1 = 1
31.21 Supply phase loss List 0…1 - 1 = 1
31.22 STO indication run/stop List 0…5 - 1 = 1
31.23 Wiring or earth fault List 0…1 - 1 = 1
31.24 Stall function List 0…2 - 1 = 1
31.25 Stall current limit Real 0.0 … 1600.0 % 10 = 1%
31.26 Stall speed limit Real 0.00 … 10000.00 rpm 100 = 1 rpm
31.27 Stall frequency limit Real 0.00 … 500.00 Hz 100 = 1 Hz
31.28 Stall time Real 0…3600 s 1 = 1 s
31.30 Overspeed trip margin Real 0.00 … 10000.00 rpm 100 = 1 rpm
31.32 Emergency ramp supervision Real 0…300 % 1 = 1%
31.33 Emergency ramp supervision
delay
Real 0…32767 s 1 = 1 s
31.35 Main fan fault function List 0…2 - 1 = 1
31.36 Aux fan fault bypass List 0…1 - 1 = 1
31.37 Ramp stop supervision Real 0…300 % 1 = 1%
31.38 Ramp stop supervision delay Real 0…32767 s 1 = 1 s
31.40 Disable warning messages PB 0000h…FFFFh - 1 = 1
31.42 Overcurrent fault limit Real 0.00 … 30000.00 A 100 = 1 A
(Parameters 31.120…31.121 only visible when IGBT supply unit control activated by 95.20)
31.120 LSU earth fault List 0…1 - 1 = 1
31.121 LSU supply phase loss List 0…1 - 1 = 1
32 Supervision
32.01 Supervision status PB 000b…111b - 1 = 1
32.05 Supervision 1 function List 0…6 - 1 = 1
32.06 Supervision 1 action List 0…3 - 1 = 1
32.07 Supervision 1 signal Analog
src
--1 = 1
32.08 Supervision 1 filter time Real 0.000 … 30.000 s 1000 = 1 s
32.09 Supervision 1 low Real -21474830.00 …
21474830.00
- 100 = 1
32.10 Supervision 1 high Real -21474830.00 …
21474830.00
- 100 = 1
32.15 Supervision 2 function List 0…6 - 1 = 1
32.16 Supervision 2 action List 0…3 - 1 = 1
32.17 Supervision 2 signal Analog
src
--1 = 1
32.18 Supervision 2 filter time Real 0.000 … 30.000 s 1000 = 1 s
No. Name Type Range Unit FbEq32
