544 Additional parameter data
58.18 EFB control word PB 0000h…FFFFh - 1 = 1
58.19 EFB status word PB 0000h…FFFFh - 1 = 1
58.25 Control profile List 0, 2 - 1 = 1
58.26 EFB ref1 type List 0…5 - 1 = 1
58.27 EFB ref2 type List 0…5 - 1 = 1
58.28 EFB act1 type List 0…6 - 1 = 1
58.29 EFB act2 type List 0…6 - 1 = 1
58.30 EFB status word transparent
source
Analog
src
--1 = 1
58.31 EFB act1 transparent source Analog
src
--1 = 1
58.32 EFB act2 transparent source Analog
src
--1 = 1
58.33 Addressing mode List 0…2 - 1 = 1
58.34 Word order List 0…1 - 1 = 1
58.36 EFB comm supervision force PB 0000h…FFFFh - 1 = 1
58.101 Data I/O 1 Analog
src
--1 = 1
58.102 Data I/O 2 Analog
src
--1 = 1
58.103 Data I/O 3 Analog
src
--1 = 1
58.104 Data I/O 4 Analog
src
--1 = 1
58.105 Data I/O 5 Analog
src
--1 = 1
58.106 Data I/O 6 Analog
src
--1 = 1
58.107 Data I/O 7 Analog
src
--1 = 1
…… … … …
58.124 Data I/O 24 Analog
src
--1 = 1
60 DDCS communication
60.01 M/F communication port List ---
60.02 M/F node address Real 1…254 - -
60.03 M/F mode List 0…6 - -
60.05 M/F HW connection List 0…1 - -
60.07 M/F link control Real 1…15 - -
60.08 M/F comm loss timeout Real 0…65535 ms -
60.09 M/F comm loss function List 0…3 - -
60.10 M/F ref1 type List 0…5 - -
60.11 M/F ref2 type List 0…5 - -
60.12 M/F act1 type List 0…5 - -
60.13 M/F act2 type List 0…5 - -
No. Name Type Range Unit FbEq32
