Parameters 183
09
09 ESP signals
ESP signals to monitor the pump.
09.01 ESP status word Displays the current state of the ESP application functions.
09.09 Drive control state Displays the current state of drive control. Drive not
ready
Drive not ready Drive is not ready for operation. 0
ID run undone No motor ID run done. Necessary to run in DTC mode. 1
Drive stopped Drive is stopped. 2
Fault active A fault is active. 3
Local control Drive is in Local control. 4
Jog mode Jogging enable signal is On. 5
Ext1 running Control location EXT1 is active. 6
Ext2 running Control location EXT2 is active. 7
Stopping Drive is stopping the motor as per deceleration ramp time
settings.
8
Em stop active Stopping after receiving an emergency stop command. 9
Constant speed Drive is running in constant speed mode. 10
09.11 Drive output current Displays actual drive output current. 0.00
0.00...30000.00 A Drive output current. 10 = 1A
09.13 Motor current
estimated
Displays the actual motor current estimate based on
transformer ratio and sine-filter settings.
0.00
0.00...30000.00 A Estimated motor current. 10 = 1A
09.14 Motor current % Displays estimated actual motor current in %. 0.00
0.00...30000.00 % Estimated motor current. 10 = 1%
09.15 Motor voltage
estimated
Displays the actual motor voltage estimate based on
transformer ratio setting.
0.00
0.00...30000.00 V Estimated motor voltage. 10 = 1V
09.21 Frequency
reference used
Displays the frequency reference currently produced by the
ESP control program.
0.00
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Production state Drive is following the ESP program reference.
1 Restart delay act Restart delay timer active.
2 Backspin observer act Backspin speed observer routine is active.
3...4 Reserved
5 Kick-start act Kick-start starting routine is active.
6 Current pulse act Current-pulse starting routine is active.
7 Underload act Underload condition is active.
8 Overload act Overload condition is active.
9...10 Reserved
11 Current boost/IR
comp. act
Voltage or current boost is active.
12 Cleaning act Pump cleaning operation is active.
13...14 Reserved
15 Time control act Time control is active.
