528 Additional parameter data
28.24 Constant frequency sel3 Binary
src
--1 = 1
28.26 Constant frequency 1 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.27 Constant frequency 2 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.28 Constant frequency 3 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.29 Constant frequency 4 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.30 Constant frequency 5 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.31 Constant frequency 6 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.32 Constant frequency 7 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.41 Frequency ref safe Real -500.00 … 500.00 Hz 100 = 1 Hz
28.51 Critical frequency function PB 00b…11b - 1 = 1
28.52 Critical frequency 1 low Real -500.00 … 500.00 Hz 100 = 1 Hz
28.53 Critical frequency 1 high Real -500.00 … 500.00 Hz 100 = 1 Hz
28.54 Critical frequency 2 low Real -500.00 … 500.00 Hz 100 = 1 Hz
28.55 Critical frequency 2 high Real -500.00 … 500.00 Hz 100 = 1 Hz
28.56 Critical frequency 3 low Real -500.00 … 500.00 Hz 100 = 1 Hz
28.57 Critical frequency 3 high Real -500.00 … 500.00 Hz 100 = 1 Hz
28.71 Freq ramp set selection Binary
src
--1 = 1
28.72 Freq acceleration time 1 Real 0.000 …1800.000 s 1000 = 1 s
28.73 Freq deceleration time 1 Real 0.000 …1800.000 s 1000 = 1 s
28.74 Freq acceleration time 2 Real 0.000 …1800.000 s 1000 = 1 s
28.75 Freq deceleration time 2 Real 0.000 …1800.000 s 1000 = 1 s
28.76 Freq ramp in zero source Binary
src
--1 = 1
28.77 Freq ramp hold Binary
src
--1 = 1
28.78 Freq ramp output balancing Real -500.00 … 500.00 Hz 100 = 1 Hz
28.79 Freq ramp out balancing
enable
Binary
src
--1 = 1
28.90 Frequency ref act 1 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.91 Frequency ref act 2 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.92 Frequency ref act 3 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.96 Frequency ref act 7 Real -500.00 … 500.00 Hz 100 = 1 Hz
28.97 Frequency ref unlimited Real -500.00 … 500.00 Hz 100 = 1 Hz
30 Limits
30.01 Limit word 1 PB 0000h…FFFFh - 1 = 1
30.02 Torque limit status PB 0000h…FFFFh - 1 = 1
30.11 Minimum speed Real -30000.00 … 30000.00 rpm 100 = 1 rpm
30.12 Maximum speed Real -30000.00 … 30000.00 rpm 100 = 1 rpm
30.13 Minimum frequency Real -500.00 … 500.00 Hz 100 = 1 Hz
30.14 Maximum frequency Real -500.00 … 500.00 Hz 100 = 1 Hz
30.15 Maximum start current enable List 0…1 - 1 = 1
