Parameters 285
26.74 Torque ref ramp out Displays the torque reference after limiting and ramping. See
the control chain diagram on page 651.
This parameter is read-only.
-
-1600.0 … 1600.0% Torque reference after limiting and ramping. See par.
46.03
26.75 Torque reference
act 5
Displays the torque reference after control mode selection.
See the control chain diagram on page 653.
This parameter is read-only.
-
-1600.0 … 1600.0% Torque reference after control mode selection. See par.
46.03
26.76 Torque reference
act 6
Displays the torque reference after application of reference
additive 2. See the control chain diagram on page 653.
This parameter is read-only.
-
-1600.0 … 1600.0% Torque reference after application of reference additive 2. See par.
46.03
26.77 Torque ref add A
actual
Displays the value of the source of torque reference additive
2. See the control chain diagram on page 653.
This parameter is read-only.
-
-1600.0 … 1600.0% Torque reference additive 2. See par.
46.03
26.78 Torque ref add B
actual
Displays the value of torque reference additive 2 before it is
added to torque reference. See the control chain diagram on
page 653.
This parameter is read-only.
-
-1600.0 … 1600.0% Torque reference additive 2. See par.
46.03
26.81 Rush control gain Rush controller gain term. See section Rush control (page
85).
10.0
0.0 …10000.0 Rush controller gain (0.0 = disabled). 1 = 1
26.82 Rush control
integration time
Rush controller integration time term. 2.0 s
0.0 … 10.0 s Rush controller integration time (0.0 = disabled). 1 = 1 s
28
28 Frequency reference
chain
Settings for the frequency reference chain.
See the control chain diagrams on pages 656 and 657.
28.01 Frequency ref ramp
input
Displays the used frequency reference before ramping. See
the control chain diagram on page 657.
This parameter is read-only.
-
-500.00 … 500.00
Hz
Frequency reference before ramping. See par.
46.02
28.02 Frequency ref ramp
output
Displays the final frequency reference (after selection,
limitation and ramping). See the control chain diagram on
page 657.
This parameter is read-only.
-
-500.00 … 500.00
Hz
Final frequency reference. See par.
46.02
No. Name/Value Description Def/FbEq16
