Parameters 223
14.91 AO2 source max (Visible when 14.01 Module 1 type = FAIO-01)
Defines the real value of the signal (selected by parameter
14.87 AO2 source) that corresponds to the maximum AO2
output value (defined by parameter 14.93 AO2 out at AO2 src
max). See parameter 14.90 AO2 source min.
100.0
-32768.0 …
32767.0
Real signal value corresponding to maximum AO2 output
value.
1 = 1
14.92 AO2 out at AO2 src
min
(Visible when 14.01 Module 1 type = FAIO-01)
Defines the minimum output value for analog output AO2.
See also drawing at parameter 14.90 AO2 source min.
0.000 mA
0.000 … 22.000 mA Minimum AO2 output value. 1000 = 1 mA
14.93 AO2 out at AO2 src
max
(Visible when 14.01 Module 1 type = FAIO-01)
Defines the maximum output value for analog output AO2.
See also drawing at parameter 14.90 AO2 source min.
10.000 mA
0.000 … 22.000 mA Maximum AO2 output value. 1000 = 1 mA
15
15 I/O extension
module 2
Configuration of I/O extension module 2.
See also section Programmable I/O extensions (page 65).
Note: The contents of the parameter group vary according to
the selected I/O extension module type.
15.01 Module 2 type See parameter 14.01 Module 1 type. None
15.02 Module 2 location See parameter 14.02 Module 1 location. Slot 1
15.03 Module 2 status See parameter 14.03 Module 1 status. No option
15.05 DI status (Visible when 15.01 Module 2 type = FDIO-01)
See parameter 14.05 DI status.
-
15.05 DIO status (Visible when 15.01 Module 2 type = FIO-01 or FIO-11)
See parameter 14.05 DIO status.
-
15.06 DI delayed status (Visible when 15.01 Module 2 type = FDIO-01)
See parameter 14.06 DI delayed status.
-
15.06 DIO delayed status (Visible when 15.01 Module 2 type = FIO-01 or FIO-11)
See parameter 14.06 DIO delayed status.
-
15.08 DI filter time (Visible when 15.01 Module 2 type = FDIO-01)
See parameter 14.08 DI filter time.
10.0 ms
15.08 DIO filter time (Visible when 15.01 Module 2 type =
FIO-01 or FIO-11)
See parameter 14.08 DIO filter time.
10.0 ms
15.09 DIO1 function (Visible when 15.01 Module 2 type = FIO-01 or FIO-11)
See parameter 14.09 DIO1 function.
Input
15.11 DIO1 output source (Visible when 15.01 Module 2 type = FIO-01 or FIO-11)
See parameter 14.11 DIO1 output source.
Not
energized
15.12 DI1 ON delay (Visible when 15.01 Module 2 type = FDIO-01)
See parameter 14.12 DI1 ON delay.
0.00 s
15.12 DIO1 ON delay (Visible when 15.01 Module 2 type = FIO-01 or FIO-11)
See parameter 14.12 DIO1 ON delay.
0.00 s
15.13 DI1 OFF delay (Visible when 15.01 Module 2 type = FDIO-01)
See parameter 14.13 DI1 OFF delay.
0.00 s
15.13 DIO1 OFF delay (Visible when 15.01 Module 2 type = FIO-01 or FIO-11)
See parameter 14.13 DIO1 OFF delay
.
0.00 s
No. Name/Value Description Def/FbEq16
