556 Additional parameter data
85.53 Downthrust flowrate 5 Real 0.00...32000.00 - 100 = 1
85.54 Upthrust head 5 Real 0.00...32000.00 - 100 = 1
85.55 Upthrust flowrate 5 Real 0.00...32000.00 - 100 = 1
85.56 DNT zone 50% Head 5 Real 0.00...32000.00 - 100 = 1
85.57 UPT zone 50% Head 5 Real 0.00...32000.00 - 100 = 1
85.58 Workzone 1/3 Head 5 Real 0.00...32000.00 - 100 = 1
85.59 Workzone 2/3 Head 5 Real 0.00...32000.00 - 100 = 1
85.60 Curve fine tune enable List ---
85.61 Convex coef 1 Real -10.00...10.00 - 100 = 1
85.62 Convex coef 2 Real -10.00...10.00 - 100 = 1
85.63 Convex coef 3 Real -10.00...10.00 - 100 = 1
85.64 Convex coef 4 Real -10.00...10.00 - 100 = 1
85.65 Convex coef 5 Real -10.00...10.00 - 100 = 1
85.66 Convex coef 6 Real -10.00...10.00 - 100 = 1
85.67 Convex coef 7 Real -10.00...10.00 - 100 = 1
85.71 Aux input data 1 Real -32000.00...32000.00 - 100 = 1
85.72 Aux input data 2 Real -32000.00...32000.00 - 100 = 1
85.79 Function type List ---
85.90 Q for the next H-point Real 0.00...30000.00 - 100 = 1
85.91 Flowrate actual Real 0.00...30000.00 0 100 = 1
85.92 Head actual Real 0.00...30000.00 - 100 = 1
85.99 Pump curves status word PB 0b0000…0b111111111111
1111
--
90 Feedback selection
90.01 Motor speed for control Real -32768.00 … 32767.00 rpm 100 = 1 rpm
90.02 Motor position Real 0.00000000 … 1.00000000 rev 100000000 =
1rev
90.03 Load speed Real -32768.00 … 32767.00 rpm 100 = 1 rpm
90.04 Load position Real -2147483648 …
2147483647
-1 = 1
90.05 Load position scaled Real -2147483.648 …
2147483.647
- 100000 = 1
90.06 Motor position scaled Real -2147483.648 …
2147483.647
- 1000 = 1
90.07 Load position scaled int Real -2147483648 …
2147483647
-1 = 1
90.10 Encoder 1 speed Real -32768.00 … 32767.00 rpm 100 = 1 rpm
90.11 Encoder 1 position Real 0.00000000 … 1.00000000 rev 100000000 =
1rev
90.12 Encoder 1 multiturn
revolutions
Real 0…16777215 - 1 = 1
90.13 Encoder 1 revolution
extension
Real -2147483648 …
2147483647
-1 = 1
90.14 Encoder 1 position raw Real 0…16777215 - 1 = 1
No. Name Type Range Unit FbEq32
