562 Additional parameter data
96.23 M/F and D2D clock
synchronization
List 0…1 - 1 = 1
96.24 Full days since 1st Jan 1980 Real 1…59999 - 1 = 1
96.25 Time in minutes within 24 h Real 0…1439 - 1 = 1
96.26 Time in ms within one minute Real 0…59999 - 1 = 1
96.29 Time sync source status PB 0000h…FFFFh - 1 = 1
96.31 Drive ID number Real 0…32767 - 1 = 1
96.53 Actual checksum Real 00000000h…FFFFFFFFh - 1 = 1
96.54 Checksum action List 0…4 - 1 = 1
96.55 Checksum control word PB 0000h…FFFFh - 1 = 1
96.56 Approved checksum 1 Real 00000000h…FFFFFFFFh - 1 = 1
96.57 Approved checksum 2 Real 00000000h…FFFFFFFFh - 1 = 1
96.58 Approved checksum 3 Real 00000000h…FFFFFFFFh - 1 = 1
96.59 Approved checksum 4 Real 00000000h…FFFFFFFFh - 1 = 1
96.61 User data logger status word PB 0000h…FFFFh - 1 = 1
96.63 User data logger trigger Binary
src
---
96.64 User data logger start Binary
src
---
96.65 Factory data logger time level List --1 = 1
96.70 Disable adaptive program List 0…1 - 1 = 1
(Parameters 96.100…96.102 only visible when enabled by parameter 96.02)
96.100 Change user pass code Data 10000000…99999999 - 1 = 1
96.101 Confirm user pass code Data 10000000…99999999 - 1 = 1
96.102 User lock functionality PB 0000h…FFFFh - 1 = 1
(Parameter 96.108 only visible when IGBT supply unit control activated by 95.20)
96.108 LSU control board boot Real 0…1 - 1 = 1
97 Motor control
97.01 Switching frequency reference Real 0.000 … 24.000 kHz 1000 = 1%
97.02 Minimum switching frequency Real 0.000 … 24.000 kHz 1000 = 1%
97.03 Slip gain Real 0…200 % 1 = 1%
97.04 Voltage reserve Real -4…50 % 1 = 1%
97.05 Flux braking List 0…2 - 1 = 1
97.06 Flux reference select Binary
src
--1 = 1
97.07 User flux reference Real 0.00 … 200.00 % 100 = 1%
97.08 Optimizer minimum torque Real 0.0 … 1600.0 % 10 = 1%
97.09 Switching freq mode List 0…3 - 1 = 1
97.10 Signal injection List 0…4 - 1 = 1
97.11 TR tuning Real 25…400 % 1 = 1%
97.12 IR comp step-up frequency Real 0.0 … 50.0 Hz 10 = 1 Hz
97.13 IR compensation Real 0.00 … 50.00 % 100 = 1%
No. Name Type Range Unit FbEq32
