ABB ACS880-04XT User Manual

440 Parameters
EFB1 ref See parameter 03.09 EFB reference 1 (page 156). 5
EFB2 ref See parameter 03.10 EFB reference 2 (page 156). 6
Other Source selection (see Terms and abbreviations on page 148). -
80.40 IR compensation
enable
Defines the source for the IR compensation enable signal. ESP CW bit
11
Not selected Validate tuning cmd is not selected. 0
Selected Validate tuning cmd is selected. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 8
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 9
ESP CW bit 11 Parameter 74.01 ESP control word, bit-11 status controls
enable/disable status of the function.
10
Other Source selection (see Terms and abbreviations on page 148). -
80.41 IR compensation
ref
Defines IR compensation reference value that produces
relative output voltage boost.
0.00
0.00...50.00 % IR compensation reference. 10 = 1%
80.42 Step up frequency Defines step-up frequency reference used for IR-
compensation.
2.00
2.00...300.00 Hz Step up frequency. 10 = 1Hz
80.80 Flux correction Displays change in flux reference calculated out of additive
voltage settings in custom user U/F curve.
0.00
-100.00...100.00 % Flux correction. 10 = 1%
80.81 Flux reference Displays the flux reference used for the motor control when
U/F curve setting is in use.
Note: This value has no effect if energy optimization is
enabled.
0.00
0.00...200.00 % Flux reference. 10 = 1%
80.82 Actual additive
voltage
Displays the used additive voltage based on U/F curve setting
and actual motor speed.
0.00
-100.00...100.00 % Actual additive voltage. 10 = 1%
81
81 Pump cleaning
Enables pump cleaning function.
See section Pump impeller cleaning (page 59).
81.01 Pump cleaning
enable
Defines the source for the Cleaning function enable signal.
The function requires enable signal ON + some of the triggers
active. This creates a cleaning request. If both conditions are
achieved, then the drive is started.
The ESP control program will first perform the cleaning
routine as per settings in parameters 81.20...81.48. From the
last cleaning step, the function will automatically continue to
production operation.
Note: Cleaning function cannot be triggered when motor is
running.
ESP CW bit
12
No. Name/Value Description Def/FbEq16
