Additional parameter data 551
75.50 Kick start enable List ---
75.51 Kick start hold time Real 0.0...30.0 s 10 = 1s
75.52 Kick start speed reference Real 40.0...100.0 % 10 = 1s
75.56 Kick start current ref Real 0.0...300.0 % 10 = 1%
75.57 Kick start current ramp Real 0.0...1000.0 %/s 10 = 1%/s
75.60 Current pulse start mode
enable
List ---
75.61 Current pulse speed reference Real 4.0...100.0 % 10 = 1%
75.62 Current pulse start current ref Real 0.0...300.0 % 10 = 1%
75.68 Current pulse nr of cycles Real 0...30000 - 1 = 1
75.69 Current pulse cycle time Real 0.0...30000.0 s 10 = 1s
75.81 Pump speed ref in Real 0.00...600.00 Hz 100 = 1Hz
75.99 Starting routines status PB 0000h…FFFFh - 1 = 1
76 ESP automatic control
76.01 Auto mode enable List ---
76.02 Process control sel List ---
76.11 Auto mode start delay Real 0...30000 s 1 = 1s
76.19 Auto mode motor ramp time Real 0.0...30000.0 s 10 = 1s
76.29 Invert PI error sign List ---
76.31 Process 1 control feedback src List ---
76.33 Process 1 control set point Real 0.00...3000000.00 - 100 = 1
76.35 Process 1 max scale Real 0.00...3000000.00 - 100 = 1
76.38 Process 1 reference change
rate
Real 0.00...100000.00 %/interva
l
100 = 1
%/interval
76.39 Process 1 ref step interval Real 0.0...30000.0 s 10 = 1s
76.41 Process 1 control P-gain Real 0.000...100000.000 - 1000 = 1
76.42 Process 1 control I-time Real 0.0...1000000.0 s 10 = 1s
76.51 Process 2 control feedback src List ---
76.53 Process 2 control set point Real 0.00...3000000.00 - 100 = 1
76.55 Process 2 max scale Real 1.00...3000000.00 - 100 =1
76.58 Process 2 reference change
rate
Real 0.00...10000.00 %/interva
l
100 = 1
%/interval
76.59 Process 2 ref step interval Real 0.0...30000.0 s 10 = 1s
76.61 Process 2 control P-gain Real 0.000...100000.000 - 1000 = 1
76.62 Process 2 control I-time Real 0.0...1000000.0 s 10 = 1s
76.80 PI feedback % Real -300.00...300.00 % 100 = 1%
76.81 PI setpoint % Real -300.00...300.00 % 100 = 1%
76.82 PI error % Real -300.00...300.00 % 100 = 1%
76.83 P term Real -300.00...300.00 - 100 = 1
76.84 I term Real -300.00...300.00 - 100 = 1
76.85 PI output Real -300.00...300.00 % 100 = 1%
76.86 Process 1 feedback signal Real -30000.00...30000.00 - 100 = 1
No. Name Type Range Unit FbEq32
