204 Parameters
13.28 AO2 source max Defines the real maximum value of the signal (selected by
parameter 13.22 AO2 source) that corresponds to the
maximum required AO2 output value (defined by parameter
13.30 AO2 out at AO2 src max). See parameter 13.27 AO2
source min.
100.0
-32768.0 …
32767.0
Real signal value corresponding to maximum AO2 output
value.
1 = 1
13.29 AO2 out at AO2 src
min
Defines the minimum output value for analog output AO2.
See also drawing at parameter 13.27 AO2 source min.
0.000 mA
0.000 … 22.000 mA Minimum AO2 output value. 1000 = 1 mA
13.30 AO2 out at AO2 src
max
Defines the maximum output value for analog output AO2.
See also drawing at parameter 13.27 AO2 source min.
20.000 mA
0.000 … 22.000 mA Maximum AO2 output value. 1000 = 1 mA
13.91 AO1 data storage Storage parameter for controlling analog output AO1 eg.
through fieldbus.
In 13.12 AO1 source, select AO1 data storage. Then set this
parameter as the target of the incoming value data.
With the embedded fieldbus interface, simply set the target
selection parameter of that particular data (58.101…58.124)
to AO1 data storage.
0.00
-327.68 … 327.67 Storage parameter for AO1. 100 = 1
13.92 AO2 data storage Storage parameter for controlling analog output AO2 eg.
through fieldbus.
In 13.22 AO2 source, select AO2 data storage. Then set this
parameter as the target of the incoming value data.
With the embedded fieldbus interface, simply set the target
selection parameter of that particular data (58.101…58.124)
to AO2 data storage.
0.00
-327.68 … 327.67 Storage parameter for AO2. 100 = 1
14
14 I/O extension
module 1
Configuration of I/O extension module 1.
See also section Programmable I/O extensions (page 65).
Note: The contents of the parameter group vary according to
the selected I/O extension module type.
14.01 Module 1 type Activates (and specifies the type of) I/O extension module 1. None
None Inactive. 0
FIO-01 FIO-01. 1
FIO-11 FIO-11. 2
FDIO-01 FDIO-01. 3
FAIO-01 FAIO-01. 4
14.02 Module 1 location Specifies the slot (1…3) on the control unit of the drive into
which the I/O extension module is installed. Alternatively,
specifies the node ID of the slot on an FEA-03 extension
adapter.
Slot 1
Slot 1 Slot 1. 1
Slot 2 Slot 2. 2
Slot 3 Slot 3. 3
4…254 Node ID of the slot on the FEA-03 extension adapter. 1 = 1
