Additional parameter data 529
30.16 Maximum start current Real 0.00 … 30000.00 A 100 = 1 A
30.17 Maximum current Real 0.00 … 30000.00 A 100 = 1 A
30.18 Minimum torque sel Binary
src
--1 = 1
30.19 Minimum torque 1 Real -1600.0 … 0.0 % 10 = 1%
30.20 Maximum torque 1 Real 0.0 … 1600.0 % 10 = 1%
30.21 Minimum torque 2 source Analog
src
--1 = 1
30.22 Maximum torque 2 source Analog
src
--1 = 1
30.23 Minimum torque 2 Real -1600.0 … 0.0 % 10 = 1%
30.24 Maximum torque 2 Real 0.0 … 1600.0 % 10 = 1%
30.25 Maximum torque sel Binary
src
--1 = 1
30.26 Power motoring limit Real 0.00 … 600.00 % 100 = 1%
30.27 Power generating limit Real -600.00 … 0.00 % 100 = 1%
30.30 Overvoltage control List 0…1 - 1 = 1
30.31 Undervoltage control List 0…1 - 1 = 1
(Parameters 30.101…30.149 only visible when IGBT supply unit control activated by 95.20)
30.101 LSU limit word 1 PB 0000h…FFFFh - 1 = 1
30.102 LSU limit word 2 PB 0000h…FFFFh - 1 = 1
30.103 LSU limit word 3 PB 0000h…FFFFh - 1 = 1
30.104 LSU limit word 4 PB 0000h…FFFFh - 1 = 1
30.148 LSU minimum power limit Real -200.0 … 0.0 % 10 = 1%
30.149 LSU maximum power limit Real 0.0 … 200.0 % 10 = 1%
31 Fault functions
31.01 External event 1 source Binary
src
--1 = 1
31.02 External event 1 type List 0…3 - 1 = 1
31.03 External event 2 source Binary
src
--1 = 1
31.04 External event 2 type List 0…3 - 1 = 1
31.05 External event 3 source Binary
src
--1 = 1
31.06 External event 3 type List 0…3 - 1 = 1
31.07 External event 4 source Binary
src
--1 = 1
31.08 External event 4 type List 0…3 - 1 = 1
31.09 External event 5 source Binary
src
--1 = 1
31.10 External event 5 type List 0…3 - 1 = 1
31.11 Fault reset selection Binary
src
--1 = 1
31.12 Autoreset selection PB 0000h…FFFFh - 1 = 1
