Additional parameter data 505

Parameter groups 1…9

No. Name Type Range Unit FbEq32

01 Actual values

01.01 Motor speed used Real -30000.00 … 30000.00 rpm 100 = 1 rpm

01.02 Motor speed estimated Real -30000.00 … 30000.00 rpm 100 = 1 rpm

01.03 Motor speed % Real -1000.00 … 1000.00 % 100 = 1%

01.04 Encoder 1 speed filtered Real -30000.00 … 30000.00 rpm 100 = 1 rpm

01.05 Encoder 2 speed filtered Real -30000.00 … 30000.00 rpm 100 = 1 rpm

01.06 Output frequency Real -500.00 … 500.00 Hz 100 = 1 Hz

01.07 Motor current Real 0.00 … 30000.00 A 100 = 1 A

01.08 Motor current % of motor nom Real 0.0 … 1000.0 % 10 = 1%

01.10 Motor torque Real -1600.0 … 1600.0 % 10 = 1%

01.11 DC voltage Real 0.00 … 2000.00 V 100 = 1 V

01.13 Output voltage Real 0…2000 V 1 = 1 V

01.14 Output power Real -32768.00 … 32767.00 kW or hp 100 = 1 unit

01.15 Output power % of motor nom Real -300.00 … 300.00 % 10 = 1%

01.17 Motor shaft power Real -32768.00 … 32767.00 kW or hp 100 = 1 unit

01.18 Inverter GWh motoring Real 0…32767 GWh 1 = 1 GWh

01.19 Inverter MWh motoring Real 0…999 MWh 1 = 1 MWh

01.20 Inverter kWh motoring Real 0…999 kWh 1 = 1 kWh

01.21 U-phase current Real -30000.00 … 30000.00 A 100 = 1 A

01.22 V-phase current Real -30000.00 … 30000.00 A 100 = 1 A

01.23 W-phase current Real -30000.00 … 30000.00 A 100 = 1 A

01.24 Flux actual % Real 0…200 % 1 = 1%

01.29 Speed change rate Real -15000 … 15000 rpm/s 1 = 1 rpm/s

01.30 Nominal torque scale Real 0.000… N·m or

lb·ft

1000 = 1 unit

01.31 Ambient temperature Real -40 … 120 °C or °F 10 = 1°

01.32 Inverter GWh regenerating Real 0…32767 GWh 1 = 1 GWh

01.33 Inverter MWh regenerating Real 0…999 MWh 1 = 1 MWh

01.34 Inverter kWh regenerating Real 0…999 kWh 1 = 1 kWh

01.35 Mot - regen energy GWh Real -32768 … 32767 GWh 1 = 1 GWh

01.36 Mot - regen energy MWh Real -999…999 MWh 1 = 1 MWh

01.37 Mot - regen energy kWh Real -999…999 kWh 1 = 1 kWh

01.61 Abs motor speed used Real 0.00 … 30000.00 rpm 100 = 1 rpm

01.62 Abs motor speed% Real 0.00 … 1000.00 % 100 = 1%

01.63 Abs output frequency Real

0.00 … 500.00 Hz 100 = 1 Hz

01.64 Abs motor torque Real 0.0 … 1600.0 % 10 = 1%

01.65 Abs output power Real 0.00 … 32767.00 kW or hp 100 = 1 unit

01.66 Abs output power % motor

nom

Real 0.00 … 300.00 % 10 = 1%

01.68 Abs motor shaft power Real 0.00 … 32767.00 kW or hp 100 = 1 unit
