406 Parameters
Warning The drive generates a warning (AF80 INU-LSU comm loss). 1
Fault Drive trips on 7580 INU-LSU comm loss.2
61
61 D2D and DDCS
transmit data
Defines the data sent to the DDCS link.
See also parameter group 60 DDCS communication.
61.01 M/F data 1
selection
Preselects the data to be sent as word 1 onto the
master/follower link.
See also parameter 61.25 M/F data 1 value, and section
Master/follower functionality (page 68).
Follower CW
None None. 0
CW 16bit Control Word (16 bits) 1
SW 16bit Status Word (16 bits) 4
Act1 16bit Actual value ACT1 (16 bits)
Note: Using this setting to send a reference to the follower is
not recommended as the source signal is filtered. Use the
“reference” selections instead.
5
Act2 16bit Actual value ACT2 (16 bits)
Note: Using this setting to send a reference to the follower is
not recommended as the source signal is filtered. Use the
“reference” selections instead.
6
Follower CW A word consisting of bits 0…11 of 06.01 Main control word
and the bits selected by parameters 06.45…06.48.
Note: Bit 3 of the follower control word is kept on as long as
the master is modulating, and when it switches to 0, the
follower coasts to a stop.
27
Used speed
reference
24.01 Used speed reference (page 263). 6145
Torque reference
act 5
26.75 Torque reference act 5 (page 285). 6731
Torque reference
used
26.02 Torque reference used (page 279). 6658
ACS800 System
ctrl SW
A follower status word compatible with an ACS800 (System
Control Program) master. With this setting, status word bit 0 is
cleared whenever the run enable signal is missing.
28
Other Source selection (see Terms and abbreviations on page 148). -
61.02 M/F data 2
selection
Preselects the data to be sent as word 2 onto the
master/follower link.
See also parameter 61.26 M/F data 2 value.
For the selections, see parameter 61.01 M/F data 1 selection.
Used speed
reference
61.03 M/F data 3
selection
Preselects the data to be sent as word 3 onto the
master/follower link.
See also parameter 61.27 M/F data 3 value
.
For the selections, see parameter 61.01 M/F data 1 selection.
Torque
reference act
5
61.25 M/F data 1 value Displays the data to be sent onto the master/follower link as
word 1 as an integer.
If no data has been preselected by 61.01 M/F data 1
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 1 in master/follower communication.
