Parameters 279
25.57 Torque reference
unbalanced
Displays the acceleration-compensated output of the speed
controller. See the control chain diagram on page 650.
This parameter is read-only.
-
-30000.0 …
30000.0%
Acceleration-compensated output of speed controller. See par.
46.03
26
26 Torque reference
chain
Settings for the torque reference chain.
See the control chain diagrams on pages 651 and 653.
26.01 Torque reference to
TC
Displays the final torque reference given to the torque
controller in percent. This reference is then acted upon by
various final limiters, like power, torque, load etc.
See the control chain diagrams on pages 653 and 654.
This parameter is read-only.
-
-1600.0 … 1600.0% Torque reference for torque control. See par.
46.03
26.02 Torque reference
used
Displays the final torque reference (in percent of motor
nominal torque) given to the DTC core, and comes after
frequency, voltage and torque limitation.
See the control chain diagram on page 654.
This parameter is read-only.
-
-1600.0 … 1600.0% Torque reference for torque control. See par.
46.03
26.08 Minimum torque ref Defines the minimum torque reference. Allows for local
limiting of the torque reference before it is passed on to the
torque ramp controller. For absolute torque limiting, refer to
parameter 30.19 Minimum torque 1.
-300.0%
-1000.0 … 0.0% Minimum torque reference. See par.
46.03
26.09 Maximum torque ref Defines the maximum torque reference. Allows for local
limiting of the torque reference before it is passed on to the
torque ramp controller. For absolute torque limiting, refer to
parameter 30.20 Maximum torque 1.
300.0%
0.0 … 1000.0% Maximum torque reference. See par.
46.03
No. Name/Value Description Def/FbEq16
