ABB RER620 Technical Manual

Section 4 1MAC309294-MB F
Protection functions
122 RER620
Technical Manual
4.1.2.10 Monitored data
Table 140: 67/51P-1 and 67/50P-1 Monitored data
Name Type Values (Range) Unit Description
PICKUP_DUR FLOAT32 0.00...100.00 % Ratio of pickup time / trip time
FAULT_DIR Enum 0=unknown
1=forward
2=backward
3=both
Detected fault direction
DIRECTION Enum 0=unknown
1=forward
2=backward
3=both
Direction information
DIR_A Enum 0=unknown
1=forward
2=backward
3=both
Direction phase A
DIR_B Enum 0=unknown
1=forward
2=backward
3=both
Direction phase B
DIR_C Enum 0=unknown
1=forward
2=backward
3=both
Direction phase C
ANGLE_A FLOAT32 -180.00...180.00 deg Calculated angle difference, Phase A
ANGLE_B FLOAT32 -180.00...180.00 deg Calculated angle difference, Phase B
ANGLE_C FLOAT32 -180.00...180.00 deg Calculated angle difference, Phase C
67/51P-1 and 67/50P-1 Enum 1=enabled
2=blocked
3=test
4=test/blocked
5=disabled
Status
