ABB RER620 Technical Manual

Section 3 1MAC309294-MB F
Basic functions
80 RER620
Technical Manual
3.11.2.3 Signals
Table 98: CONTROL input signals
Output signals
Table 99: CONTROL output signals
3.11.2.4 Settings
Table 100: CONTROL settings
Name Type Default Description
CTRL_OFF
BOOLEAN 0 Control input OFF
CTRL_LOC
BOOLEAN 0 Control input Local
CTRL_STA
BOOLEAN 0 Control input Station
CTRL_REM
BOOLEAN 0 Control input Remote
Name Type Description
OFF BOOLEAN Control output OFF
LOCAL BOOLEAN Control output Local
STATION BOOLEAN Control output Station
REMOTE BOOLEAN Control output Remote
Parameter Values (Range) Unit Step
Default
Description
LR control
1 = "LR key"
2 = "Binary input"
1 = "LR key" LR control through LR
key or binary input
Station authority 1 = "Not used"
2 = "Station
Remote"
1 = "Not used" Control command
originator category
usage
