ABB RER620 Technical Manual

Section 9 1MAC309294-MB F
Other functions
450 RER620
Technical Manual
Table 409: Truth table for SRGAPC
9.7.3 Signals
Table 410: SRGAPC Input signals
S# R# Q#
00
0
1
1. Keep state/no change
010
101
111
Name Type Default Description
S1 BOOLEAN 0=False Set Q1 output
when set
R1 BOOLEAN 0=False Resets Q1
output when set
S2 BOOLEAN 0=False Set Q2 output
when set
R2 BOOLEAN 0=False Resets Q2
output when set
S3 BOOLEAN 0=False Set Q3 output
when set
R3 BOOLEAN 0=False Resets Q3
output when set
S4 BOOLEAN 0=False Set Q4 output
when set
R4 BOOLEAN 0=False Resets Q4
output when set
S5 BOOLEAN 0=False Set Q5 output
when set
R5 BOOLEAN 0=False Resets Q5
output when set
S6 BOOLEAN 0=False Set Q6 output
when set
R6 BOOLEAN 0=False Resets Q6
output when set
S7 BOOLEAN 0=False Set Q7 output
when set
R7 BOOLEAN 0=False Resets Q7
output when set
S8 BOOLEAN 0=False Set Q8 output
when set
R8 BOOLEAN 0=False Resets Q8
output when set
