ABB RER620 Technical Manual

1MAC309294-MB F Section 5
Control functions
RER620 351
Technical Manual
5.4.6 Signals
Table 318: DLCM input signals
Table 319: DLCM output signals
Name Type Default Description
S1_ENABLE Boolean FALSE Source 1 enable or disable
S2_ENABLE Boolean FALSE Source 2 enable or disable
RESET_IN Boolean FALSE Reset input
BLOCK Boolean FALSE Block input
Name Type Description
LCM_TRIP Boolean Trip output, valid only in Sectionalize t mode
LCM_CLOSE Boolean Trip output, valid only in Tie point mode
SET_GROUP_CHANGE Boolean Output used to activate Alternate settings in mid point and tie point
modes
SWOTF Boolean Binary output to operate the recloser in lock-out or non-reclose
mode
S1_STATUS Boolean source1 status
S2_STATUS Boolean source2 status
S1_DISABLED Boolean source1 enable
S2_DISABLED Boolean source2 enable
RESET_OUT Boolean Reset output
