ABB RER620 Technical Manual

Section 5 1MAC309294-MB F
Control functions
280 RER620
Technical Manual
5.1.7 Settings
Table 291: 52 Non group settings
5.1.8 Monitored data
Table 292: 52 Monitored data
5.2 Autoreclosing 79
The RER620 single-phase tripping and reclosing option is advantageous for use on many
electric utility distribution systems, including rural, residential and some commercial
Parameter Values (Range) Unit Step Default Description
Select timeout 10000...300000 ms 10000 60000 Select timeout in ms
Pulse length 10...60000 ms 1 100 Open and close pulse length
Operation 1=Enable
5=Disable
1=Enable Operation mode on/off/test
Operation counter 0...10000 0 Breaker operation cycles
Control model 0=status-only
1=direct-with-normal-security
4=sbo-with-enhanced-security
4=sbo-with-enhanced-
security
Select control model
Adaptive pulse 0=False
1=True
1=True Stop in right position
Event delay 0...10000 ms 1 100 Event delay of the intermediate
position
Operation timeout 10...60000 ms 500 Timeout for negative termination
Operation counter A 0…10000 0 Breaker phase A operation cycles
Operation counter B 0…10000 0 Breaker phase B operation cycles
Operation counter C 0…10000 0 Breaker phase C operation cycles
Breaker Op mode • Three phase
• Single phase
Three Phase Breaker operation mode
Name Type Values (Range) Unit Description
POSITION Dbpos 0=intermediate
1=open
2=closed
3=faulty
Apparatus position indication
PHASE_A DbPos 0=Intermediate
1=open
2=closed
3=faulty
Apparatus phase A Position indication
PHASE_B DbPos 0=Intermediate
1=open
2=closed
3=faulty
Apparatus phase B Position indication
PHASE_C DbPos 0=Intermediate
1=open
2=closed
3=faulty
Apparatus phase C Position indication
