3.9.8.2 Functionality
The GOOSERCV_INT32 function block is used to connect GOOSE 32 bit integer inputs
to the application.
3.9.8.3 Signals
Table 53: GOOSERCV_INT32 Input signals
Table 54: GOOSERCV_INT32 Output signals
3.10 Type conversion function blocks
3.10.1 QTY_GOOD function block
3.10.1.1 Function block
Figure 17: Function block
3.10.1.2 Functionality
The QTY_GOOD function block evaluates the quality bits of the input signal and passes
it as a Boolean signal for the application.
The IN input can be connected to any logic application signal (logic function output,
binary input, application function output or received GOOSE signal). Due to application
logic quality bit propagation, each (simple and even combined) signal has quality which
can be evaluated.
The OUT output indicates quality good of the input signal. Input signals that have no
quality bits set or only test bit is set, will indicate quality good status.
Name Type Default Description
IN INT32 0 Input signal
Name Type Description
OUT INT32 Output signal
VALID BOOLEAN Output signal
QTY_GOOD
IN
OUT
