ABB RER620 Technical Manual

Section 7 1MAC309294-MB F
Measurement functions
394 RER620
Technical Manual
7.1.4.5 Monitored data
Table 344: IA,IB,IC Monitored data
Name Type Values (Range) Unit Description
IA-A FLOAT32 0.00...40.00 xIn Measured current amplitude phase A
IB-A FLOAT32 0.00...40.00 xIn Measured current amplitude phase B
IC-A FLOAT32 0.00...40.00 xIn Measured current amplitude phase C
Max demand phA FLOAT32 0.00...40.00 xIn Maximum demand for Phase A
Max demand phB FLOAT32 0.00...40.00 xIn Maximum demand for Phase B
Max demand phC FLOAT32 0.00...40.00 xIn Maximum demand for Phase C
Time max demand phA Timestamp Time of maximum demand phase A
Time max demand phB Timestamp Time of maximum demand phase B
Time max demand phC Timestamp Time of maximum demand phase C
I_INST_A FLOAT32 0.00...40.00 xIn IA Amplitude, magnitude of
instantaneous value
I_DB_A FLOAT32 0.00...40.00 xIn IA Amplitude, magnitude of reported
value
I_DMD_A FLOAT32 0.00...40.00 xIn Demand value of IL1 current
I_RANGE_A Enum 0=normal
1=high
2=low
3=high-high
4=low-low
IA Amplitude range
I_INST_B FLOAT32 0.00...40.00 xIn IB Amplitude, magnitude of
instantaneous value
I_DB_B FLOAT32 0.00...40.00 xIn IB Amplitude, magnitude of reported
value
I_DMD_B FLOAT32 0.00...40.00 xIn Demand value of IL2 current
I_RANGE_B Enum 0=normal
1=high
2=low
3=high-high
4=low-low
IB Amplitude range
I_INST_C FLOAT32 0.00...40.00 xIn IC Amplitude, magnitude of
instantaneous value
I_DB_C FLOAT32 0.00...40.00 xIn IC Amplitude, magnitude of reported
value
I_DMD_C FLOAT32 0.00...40.00 xIn Demand value of IL3 current
I_RANGE_C Enum 0=normal
1=high
2=low
3=high-high
4=low-low
IC Amplitude range
