1MAC309294-MB F Section 4
Protection functions
RER620 259
Technical Manual
4.5.5 Directional positive sequence power protection 32P
The directional positive sequence power protection (32P) function detects power direction
for phase directional power. Release signal is given if the angle difference polarizing and
operating quantity is in predefined direction (forward or reverse direction). The release
signal is given with definite time delay.
4.5.5.1 Identification
4.5.5.2 Function block
Figure 126: Function block
4.5.5.3 Functionality
The directional positive sequence power protection (32P) function is used to detect
positive sequence power direction. The output of the function is used for blocking or
releasing other functions in protection scheme.
This function contains a blocking functionality which blocks function output and resets the
timer.
4.5.5.4 Operation principle
The Operation setting is used to enable or disable the function. When selected “On” the
function is enabled and respectively “Off” means function is disabled.
The operation of 32P can be described by using a module diagram (see Figure 127). All
the modules in the diagram are explained in the next sections.
Functional description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Directional positive sequence power
protection
DPSRDIR P>-> 32P
