ABB RER620 Technical Manual

Section 3 1MAC309294-MB F
Basic functions
58 RER620
Technical Manual
3.9.2.3 Signals
Table 41: GOOSERCV_DP Input signals
Table 42: GOOSERCV_DP Output signals
3.9.3 GOOSERCV_MV function block
3.9.3.1 Function block
Figure 11: Function block
3.9.3.2 Functionality
The GOOSERCV_MV function is used to connect the GOOSE measured value inputs to
the application.
3.9.3.3 Signals
Table 43: GOOSERCV_MV Input signals
Table 44: GOOSERCV_MV Output signals
Name Type Default Description
IN Dbpos 00 Input signal
Name Type Description
OUT Dbpos Output signal
VALID BOOLEAN Output signal
GOOSERCV_MV
OUT
VALID
Name Type Default Description
IN FLOAT32 0 Input signal
Name Type Description
OUT FLOAT32 Output signal
VALID BOOLEAN Output signal
