ABB RER620 Technical Manual

Section 5 1MAC309294-MB F
Control functions
320 RER620
Technical Manual
5.2.11 Monitored data
Table 300: SDAIGGIO monitored outputs
Name Type Values (Range) Unit Description
ACTIVE_1A Binary 0=False
1=True
Phase A protection active for input 1
ACTIVE_1B Binary 0=False
1=True
Phase B protection active for input 1
ACTIVE_1C Binary 0=False
1=True
Phase C protection active for input 1
ACTIVE_1_3P Binary 0=False
1=True
Three phase protection active for input 1
TRIPOUT_1 Binary 0=False
1=True
Protection trip active for input 1
ACTIVE_2A Binary 0=False
1=True
Phase A protection active for input 2
ACTIVE_2B Binary 0=False
1=True
Phase B protection active for input 2
ACTIVE_2C Binary 0=False
1=True
Phase C protection active for input 2
ACTIVE_2_3P Binary 0=False
1=True
Three phase protection active for input 2
TRIPOUT_2 Binary 0=False
1=True
Protection trip active for input 2
ACTIVE_3A Binary 0=False
1=True
Phase A protection active for input 3
ACTIVE_3B Binary 0=False
1=True
Phase B protection active for input 3
ACTIVE_3C Binary 0=False
1=True
Phase C protection active for input 3
ACTIVE_3_3P Binary 0=False
1=True
Three phase protection active for input 3
TRIPOUT_3 Binary 0=False
1=True
Protection trip active for input 3
ACTIVE_4A Binary 0=False
1=True
Phase A protection active for input 4
ACTIVE_4B Binary 0=False
1=True
Phase B protection active for input 4
ACTIVE_4C Binary 0=False
1=True
Phase C protection active for input 4
ACTIVE_4_3P Binary 0=False
1=True
Three phase protection active for input 4
TRIPOUT_4 Binary 0=False
1=True
Protection trip active for input 4
ACTIVE_5A Binary 0=False
1=True
Phase A protection active for input 5
ACTIVE_5B Binary 0=False
1=True
Phase B protection active for input 5
ACTIVE_5C Binary 0=False
1=True
Phase C protection active for input 5
ACTIVE_5_3P Binary 0=False
1=True
Three phase protection active for input 5
