ABB RER620 Technical Manual

1MAC309294-MB F Section 5
Control functions
RER620 317
Technical Manual
5.2.10 Settings
Table 299: 79 Non group settings
Parameter Values (Range) Unit Step Default Description
Operation 1=On
5=Off
5=On Operation mode Off/On. Setting this setting to “Off” will
prevent tripping by any protection function!
Reclosing operation 1=Off
2=External Ctl
3=On
1=On Reclosing operation (Off, External Ctl / On)
Single phase mode 1=APAT
2=OPUP
3=OOAP
1=APAT Mode of operation for the autorecloser in single-phase
mode
Shot mode 1 0...63 0 Defines 1P or 3P operation mode per input for first reclose
shot
Shot mode 2 0...63 0 Defines 1P or 3P operation mode per input for second
reclose shot
Shot mode 3 0...63 0 Defines 1P or 3P operation mode per input for third reclose
shot
Shot mode 4 0...63 0 Defines 1P or 3P operation mode per input for fourth
reclose shot
Shot mode 5 0...63 0 Defines 1P or 3P operation mode per input for fifth reclose
shot
Enable three-phase
lockout override
1=Disable
2=Enable
1=Disable If enabled, performs a three-phase trip and lockout on the
last shot
Reclaim time 0.1...1800.0 s 0.1 10.0 Reclaim time
First reclose time 0.0...300.0 s 0.1 0.5 Reclose time for CBB1
Second reclose time 0.0...300.0 s 0.1 0.5 Reclose time for CBB2
Third reclose time 0.0...300.0 s 0.1 1.5 Reclose time for CBB3
Fourth reclose time 0.0...300.0 s 0.1 4.5 Reclose time for CBB4
Fifth reclose time 0.0...300.0 s 0.1 5.0 Reclose time for CBB5
Sixth reclose time 0.0...300.0 s 0.1 5.0 Reclose time for CBB6
Seventh reclose time 0.0...300.0 s 0.1 5.0 Reclose time for CBB7
Manual close mode 0=False
1=True
0=False Manual close mode
Wait close time 0.05...10.00 s 0.01 0.25 Allowed CB closing time after reclose command
Max wait time 0.1...1800.0 s 0.1 10.0 Maximum wait time for BLK_RECL_T reclease (from
master)
Max trip time 0.1...10.0 s 0.1 10.0 Maximum wait time for protection signal deactivation
CB close pulse time 0.01...10.00 s 0.01 0.2 Close pulse time
Max thm block time 0.1...1800.0 s 0.1 10.0 Maximum wait time for thermal blocking deactivation
Cut-out time 0.1...1800.0 s 0.1 10.0 Protection coordination signal cut-out time
Dsr time shot 1 0.00...10.00 s 0.01 0.00 Discrimination time for first reclosing
Dsr time shot 2 0.00...10.00 s 0.01 0.00 Discrimination time for second reclosing
Dsr time shot 3 0.00...10.00 s 0.01 0.00 Discrimination time for third reclosing
Dsr time shot 4 0.00...10.00 s 0.01 0.00 Discrimination time for fourth reclosing
Terminal priority 1=None
2=Low (follower)
3=High (master)
1=None Terminal priority
