Section 3 1MAC309294-MB F
Basic functions
64 RER620
Technical Manual
3.10.3 T_HEALTH function block
3.10.3.1 Function block
Figure 19: Function block
3.10.3.2 Functionality
The T_HEALTH function evaluates enumerated data of “Health” data attribute. This
function block can only be used with GOOSE.
The IN input can be connected to GOOSERCV_ENUM function block, which is receiving
the LD0.LLN0.Health.stVal data attribute sent by another protection relay.
The outputs OK, WARNING and ALARM are extracted from the enumerated input value.
Only one of the outputs can be active at a time. In case the GOOSERCV_ENUM function
block doesn't receive the value from the sending relay or it is invalid, the default value (0)
is used and the ALARM is activated in the T_HEALTH function block.
3.10.3.3 Signals
Table 59: T_HEALTH Input signals
Table 60: T_HEALTH Output signals
3.10.4 T_F32_INT8 function block
Function block
Figure 20: Function block
T_HEALTH
IN1
OK
WARNING
ALARM
Name Type Default Description
IN Any 0 Input signal
Name Type Description
OK BOOLEAN Output signal
WARNING BOOLEAN Output signal
ALARM BOOLEAN Output signal
