1MAC309294-MB F Section 3
Basic functions
RER620 59
Technical Manual
3.9.4 GOOSERCV_INT8 function block
3.9.4.1 Function block
Figure 12: Function block
3.9.4.2 Functionality
The GOOSERCV_INT8 function is used to connect the GOOSE 8 bit integer inputs to the
application.
3.9.4.3 Signals
Table 45: GOOSERCV_INT8 Input signals
Table 46: GOOSERCV_INT8 Output signals
3.9.5 GOOSERCV_INTL function block
3.9.5.1 Function block
Figure 13: Function block
3.9.5.2 Functionality
The GOOSERCV_INTL function is used to connect the GOOSE double binary input to
the application and extracting single binary position signals from the double binary
position signal.
The OP output signal indicates that the position is open. Default value (0) is used if VALID
output indicates invalid status.
Name Type
Default
Description
IN INT8
0
Input signal
Name Type Description
OUT INT8 Output signal
VALID BOOLEAN Output signal
GOOSERCV_INTL
POS_OP
VALID
POS_CL
POS_OK
