1MAC309294-MB F Section 9
Other functions
RER620 447
Technical Manual
9.6 Generic control points SPCGGIO
9.6.1 Function block
Figure 232: Function block
9.6.2 Functionality
The generic control points function block SPCGGIO can be used in combination with
other function blocks such as FKEYGGIO. This block offers the capability to activate its
output through a local or remote control. The local control is issued through the buttons in
the front panel and the remote control is issued through communications. This block has
two modes of operation. In pulsed mode, regardless of local or remote, the block generates
an output pulse of preset duration. In toggle mode, a local pushbutton simply toggles the
output signal for every input pulse received, whereas a remote command only does
SET/RESET.
SPCSO1.output Remote Command SPCSO1.output
TRUE SET TRUE
TRUE RESET FALSE
FALSE SET TRUE
FALSE RESET FALSE
The status of SPCGGIO outputs ARE saved to non-volatile memory, so the relay can
memorize these outputs even when power is cycled.
The input and output of SPCGGIO are mapped to the same IEC 61850 data path. Any ACT
block that is connected to the input of a SPCGGIO must have a smaller execution order
than SPCGGIO.
IN1
IN2
IN3
IN4
IN5
IN6
IN7
IN8
IN9
IN10
IN11
IN12
IN13
IN14
IN15
IN16
O1
O2
O3
O4
O5
O6
O7
O8
O9
O10
O11
O12
O13
O14
O15
O16
SPCGGIO
