ABB RER620 Technical Manual

Section 3 1MAC309294-MB F
Basic functions
72 RER620
Technical Manual
Signals
Table 79: R_TRIG Input signals
Table 80: R_TRIG Output signals
Settings
The function does not have any parameters available in LHMI or Protection and Control
Relay Manager (PCM600).
3.11.1.9 F_TRIG function block
Function block
Figure 28: Function block
Functionality
F_Trig is used as a falling edge detector.
The function detects the transition from TRUE to FALSE at the CLK input. When the
falling edge is detected, the element assigns the Q output to TRUE. At the next execution
round, the output is returned to FALSE despite the state of the input.
Signals
Table 81: F_TRIG Input signals
Table 82: F_TRIG Output signals
Settings
The function does not have any parameters available in LHMI or Protection and Control
Relay Manager (PCM600).
Name Type Default Description
CLK BOOLEAN 0 Input signal
Name Type Description
O BOOLEAN Output signal
Name Type Default Description
CLK BOOLEAN 0 Input signal
Name Type Description
O BOOLEAN Output signal
F_TRIG
CLK
O
