ABB RER620 Technical Manual

1MAC309294-MB F Section 3
Basic functions
RER620 65
Technical Manual
3.10.4.1 Functionality
T_F32_INT8 is a type conversion function.
The function converts 32-bit floating type values to 8-bit integer type. The rounding
operation is included. Output value saturates if the input value is below the minimum or
above the maximum value.
Table 61: T_F32_INT8 Input signals
Table 62: T_F32_INT8 Output signals
3.10.4.2 Settings
The function does not have any parameters available in LHMI or Protection and Control
relay Manager (PCM600).
3.11 Configurable logic blocks
3.11.1 Standard configurable logic blocks
3.11.1.1 OR function block
Function block
Figure 21: Function blocks
3.11.1.2 Functionality
OR and OR6 are used to form general combinatory expressions with Boolean variables.
Name Type Default Description
F32 FLOAT32 0.0 Input signal
Name Type Description
INT8 INT8 Output signal
OR
B1
B2
O
B1
B2
O
B3
B4
B5
B6
OR6
