ABB RER620 Technical Manual

1MAC309294-MB F Section 3
Basic functions
RER620 57
Technical Manual
3.9.1 GOOSERCV_BIN function block
3.9.1.1 Function block
Figure 9: Function block
3.9.1.2 Functionality
The GOOSERCV_BIN function is used to connect the GOOSE binary inputs to the
application.
3.9.1.3 Signals
Table 39: GOOSERCV_BIN Input signals
Table 40: GOOSERCV_BIN Output signals
3.9.2 GOOSERCV_DP function block
3.9.2.1 Function block
Figure 10: Function block
3.9.2.2 Functionality
The GOOSERCV_DP function is used to connect the GOOSE double binary inputs to the
application.
GOOSERCV_BIN
OUT
VALID
Name Type Default Description
IN BOOLEAN 0 Input signal
Name Type Description
OUT BOOLEAN Output signal
VALID BOOLEAN Output signal
GOOSERCV_DP
OUT
VALID
