ABB RER620 Technical Manual

1MAC309294-MB F Section 8
Recording functions
RER620 421
Technical Manual
Table 379: Non-group analog channel settings for digital fault recorder
Table 380: Non-group binary channel settings for digital fault recorder
Table 381: Control data for digital fault recorder
8.1.6 Monitored data
Table 382: Monitored data for digital fault recorder
Parameter Values (Range) Unit Step Default Description
Operation 1=on
5=off
1 1=on Analog channel is enabled or disabled.
Channel selection 1 = IA
2 = IB
3 = IC
4 = IG
5 = VA
6 = VB
7 = VC
8 = VA2
9 = VB2
10 = VC2
11 = Disabled
12 = Disabled
0 0=Disabled Select the signal to be recorded by this channel. Applicable values
for this parameter are product variant dependent. Every product
variant includes only the values that are applicable to that particular
variant
Channel id text 0 to 64
characters,
alphanumeric
DR analog
channel X
Identification text for the analog channel used in the COMTRADE
format
High trigger level 0.00...60.00 pu 0.01 10.00 High trigger level for the analog channel
Low trigger level 0.00...2.00 pu 0.01 0.00 Low trigger level for the analog channel
Storage mode 0=Waveform
1=Trend / cycle
1 0 Storage mode for the analog channel
Parameter Values (Range) Unit Step Default Description
Operation 1=on
5=off
1 5=off Binary channel is enabled or disabled
Level trigger mode 1=Positive or Rising
2=Negative or Falling
3=Both
4=Level trigger off
1 1=Rising Level trigger mode for the binary channel
Storage mode 0=Waveform
1=Trend / cycle
1 0 Storage mode for the binary channel
Channel id text 0 to 64 characters, alphanumeric DR binary
channel X
Identification text for the analog channel used in the
COMTRADE format
Parameter Values (Range) Unit Step Default Description
Trig recording 0=Cancel
1=Trig
Trigger the disturbance recording
Clear recordings 0=Cancel
1=Clear
Clear all recordings currently in memory
Parameter Values (Range) Unit Step Default Description
Number of recordings 0...100 Number of recordings currently in memory
Rem. amount of rec. 0...100 Remaining amount of recordings that fit into the available recording memory,
when current settings are used
Rec. memory used 0...100 % Storage mode for the binary channel
Time to trigger 0...604 800 s Time remaining to the next periodic triggering
