ABB RER620 Technical Manual

1MAC309294-MB F Section 4
Protection functions
RER620 169
Technical Manual
4.1.4.12 Monitored data
Table 180: 67/51N and 67/50N-1 Monitored data
Table 181: 67/50N-2 Monitored data
Name Type
Values
(Range)
Unit Description
FAULT_DIR Enum 0=unknown
1=forward
2=backward
3=both
Detected fault direction
PICKUP_DUR FLOAT
32
0.00...100.00 % Ratio of pickup time / trip time
DIRECTION Enum 0=unknown
1=forward
2=backward
3=both
Direction information
ANGLE FLOAT
32
-180.00...180.
00
de
g
Angle between polarizing and operating quantity
ANGLE_RCA FLOAT
32
-180.00...180.
00
de
g
Angle between operating angle and characteristic
angle
I_OPER FLOAT
32
0.00...40.00 Calculated operating current
67/51N and
67/50N-1
Enum 1=enabled
2=blocked
3=test
4=test/blocke
d
5=disabled
Status
Name Type Values (Range) Unit Description
FAULT_DIR Enum 0=unknown
1=forward
2=backward
3=both
Detected fault direction
PICKUP_DUR FLOAT32 0.00...100.00 % Ratio of pickup time / trip time
DIRECTION Enum 0=unknown
1=forward
2=backward
3=both
Direction information
ANGLE FLOAT32 -180.00...180.00 deg Angle between polarizing and operating quantity
ANGLE_RCA FLOAT32 -180.00...180.00 deg Angle between operating angle and
characteristic angle
I_OPER FLOAT32 0.00...40.00 Calculated operating current
67/50N-2 Enum 1=enabled
2=blocked
3=test
4=test/blocked
5=disabled
Status
