ABB RER620 Technical Manual

1MAC309294-MB F Section 5
Control functions
RER620 355
Technical Manual
5.5.5 Signals
Table 321: UDFCNT input signals
Table 322: UDFCNT output signals
Table 323: UDFCNT Monitored inputs signals
Table 324: UDFCNT Monitored output signals
5.5.6 Settings
Table 325: UDFCNT non-group settings
Name Type Default Description
UP_CNT BOOL FALSE Input for up counting
DOWN_CNT BOOL FALSE Input for down counting
LOAD BOOL FALSE Load the counter to preset value
RESET BOOL FALSE Reset of the function
Name Type Description
UPCNT_STS BOOL Status of the up counting
DNCNT_STS BOOL Status of the down counting
Name Type Default Description
UP_CNT BOOL FALSE Input for up counting
DOWN_CNT BOOL FALSE Input for down counting
LOAD BOOL FALSE Load the counter to preset value
RESET BOOL FALSE Reset of the function
Name Type Description
UPCNT_STS BOOL Status of the up counting
DNCNT_STS BOOL Status of the down counting
CNT_VAL INTEGE
R
Output of counter
Parameter Values (Range) Unit Step Default Description
Operation Off
On
- On Operation Mode On/Off
Counter Load
Value
0....214748364
7
- 1 10000 Preset Counter Value
Reset Counter Cancel
Reset
- Cancel Reset Counter Value
Preset Counter Cancel
Load
- Cancel Load Counter Value to preset value
