Section 5 1MAC309294-MB F
Control functions
314 RER620
Technical Manual
5.2.9 Signals
Table 297: 79 input signals
Name Type Default Description
TRIP_1A Binary 0=False AR initialization / trip signal, input 1, phase A
TRIP_1B Binary 0=False AR initialization / trip signal, input 1, phase B
TRIP_1C Binary 0=False AR initialization / trip signal, input 1, phase C
TRIP_1_3P Binary 0=False AR initialization / trip signal, input 1, three phase
TRIP_1N Binary 0=False AR initialization / trip signal, input 1, neutral
PICKUP_1A Binary 0=False AR start / pickup signal, input 1, phase A
PICKUP_1B Binary 0=False AR start / pickup signal, input 1, phase B
PICKUP_1C Binary 0=False AR start / pickup signal, input 1, phase C
TRIP_2A Binary 0=False AR initialization / trip signal, input 2, phase A
TRIP_2B Binary 0=False AR initialization / trip signal, input 2, phase B
TRIP_2C Binary 0=False AR initialization / trip signal, input 2, phase C
TRIP_2_3P Binary 0=False AR initialization / trip signal, input 2, three phase
TRIP_2N Binary 0=False AR initialization / trip signal, input 2, neutral
PICKUP_2A Binary 0=False AR start / pickup signal, input 2, phase A
PICKUP_2B Binary 0=False AR start / pickup signal, input 2, phase B
PICKUP_2C Binary 0=False AR start / pickup signal, input 2, phase C
TRIP_3A Binary 0=False AR initialization / trip signal, input 3, phase A
TRIP_3B Binary 0=False AR initialization / trip signal, input 3, phase B
TRIP_3C Binary 0=False AR initialization / trip signal, input 3, phase C
TRIP_3_3P Binary 0=False AR initialization / trip signal, input 3, three phase
TRIP_3N Binary 0=False AR initialization / trip signal, input 3, neutral
PICKUP_3A Binary 0=False AR start / pickup signal, input 3, phase A
PICKUP_3B Binary 0=False AR start / pickup signal, input 3, phase B
PICKUP_3C Binary 0=False AR start / pickup signal, input 3, phase C
TRIP_4A Binary 0=False AR initialization / trip signal, input 4, phase A
TRIP_4B Binary 0=False AR initialization / trip signal, input 4, phase B
TRIP_4C Binary 0=False AR initialization / trip signal, input 4, phase C
TRIP_4_3P Binary 0=False AR initialization / trip signal, input 4, three phase
TRIP_4N Binary 0=False AR initialization / trip signal, input 4, neutral
PICKUP_4A Binary 0=False AR start / pickup signal, input 4, phase A
PICKUP_4B Binary 0=False AR start / pickup signal, input 4, phase B
PICKUP_4C Binary 0=False AR start / pickup signal, input 4, phase C
TRIP_5A Binary 0=False AR initialization / trip signal, input 5, phase A
TRIP_5B Binary 0=False AR initialization / trip signal, input 5, p
hase B
TRIP_5C Binary 0=False AR initialization / trip signal, input 5, phase C
TRIP_5_3P Binary 0=False AR initialization / trip signal, input 5, three phase
TRIP_5N Binary 0=False AR initialization / trip signal, input 5, neutral
PICKUP_5A Binary 0=False AR start / pickup signal, input 5, phase A
