ABB RER620 Technical Manual

Section 9 1MAC309294-MB F
Other functions
440 RER620
Technical Manual
9.2.4 Signals
Table 392: UPD input signals
9.2.5 Settings
Table 393: Non-group settings for UPD RA01 and RA02
9.2.6 Monitored data
Table 394: UPD monitored inputs
Name Type Default Description
Pole Status
Phase A
BOOLEAN 0=False True if Pole A is open, false if closed.
Pole Status
Phase B
BOOLEAN 0=False True if Pole B is open, false if closed.
Pole Status
Phase C
BOOLEAN 0=False True if Pole C is open, false if closed.
Block for 69 BOOLEAN 0=False Block close for 69 function
Parameter Values (Range) Unit Step Default Description
Actuator Selection Profile 15/27OVR 550 Turn Coil
38kv 560 Turn Coil
15/27kv OVR A0 310 turns
38kv OVR 600 turns
15/27kv OVR SCA
38kv OVR SCA
G&W Viper-ST
Custom2
Funct. Appl. A
Funct. Appl. B
Actuator selection profile
Name Type Values (Range) Unit Description
Pole Status Phase A Binary 0=False
1=True
1 True if Pole A is open, false if closed.
Pole Status Phase B Binary 0=False
1=True
1 True if Pole B is open, false if closed.
Pole Status Phase C Binary 0=False
1=True
1 True if Pole C is open, false if closed.
Block for 69 Binary 0=False
1=True
1 Block close for 69 function
