ABB RER620 Technical Manual

1MAC309294-MB F Section 13
Technical data
RER620 563
Technical Manual
Section 13 Technical data
Table 443: Dimensions
Table 444: Power supply
Description Value
Width frame 10.32 inches (262.2 mm)
case 9.69 inches (246 mm)
Height frame 6.97 inches (177 mm), 4U
case 6.30 inches (160 mm)
Depth 7.91 inches (201 mm)
Weight Complete relay 10.5 lbs (4.8 kg)
Plug-in unit only 6.0 lbs (2.8 kg)
Description Type 2
V nominal (V
n
)60 V DC
V
n
variation 50 to 120% of V
n
(30 to 72 V DC)
Start-up threshold 48 V DC
(60 V DC × 80%)
Burden of auxiliary voltage supply under quiescent
(P
q
)/operating condition
DC < 6.9 W (nominal)/< 13.3 W (max)
Ripple in the DC auxiliary voltage Max 12% of the DC value (at frequency of 2 × f
n
Hz)
Maximum interruption time in the auxiliary DC
voltage without resetting the relay
50 ms at 60 V DC
Fuse type T4A/250 V
