Section 6 Condition monitoring functions
6.1 Circuit breaker condition monitoring 52CM
6.1.1 Identification
6.1.2 Function block
Figure 191: Function block
6.1.3 Functionality
The circuit breaker condition monitoring function 52CM is used to monitor different
parameters of the circuit breaker. The breaker requires maintenance when the number of
operations has reached a predefined value. For proper functioning of the circuit breaker, it
is essential to monitor the circuit breaker operation, spring charge indication, breaker wear,
travel time, number of operation cycles and accumulated energy. The energy is calculated
from the measured input currents as a sum of I
y
t values. Alarms are generated when the
calculated values exceed the threshold settings.
The function contains a blocking functionality. It is possible to block the function outputs,
if desired.
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Circuit breaker condition monitoring SPSCBR CBCM 52CM
52CM
I_C
BLOCK
POSOPEN_A
PRES_ALM_IN
PRES_LO_IN
SPR_ CHR_ST
SPR_ CHR
RST_ IPOW
RST_CB_ WEAR
TRV_T_OP_ ALM
TRV_T_CL_ ALM
SPR_ CHR_ALM
OPR_ALM
OPR_LO
IPOW_ALM
IPOW_LO
CB_ LIFE_ ALM
MON_ ALM
PRES_ ALM
PRES_LO
OPENPOS_A
INVALIDPOS_A
CLOSEPOS_A
I_A
I_B
RST_TRV_T
RST_ SPR_T
POSOPEN_B
POSOPEN_C
POSCLOSE_A
POSCLOSE_B
POSCLOSE_C
OPENPOS_B
OPENPOS_C
INVALIDPOS_B
INVALIDPOS_C
CLOSEPOS_B
CLOSEPOS_C
