Section 7 1MAC309294-MB F
Measurement functions
402 RER620
Technical Manual
7.1.8.4 Settings
Table 362: I1, I2, I0 Non group settings
Parameter Values (Range) Unit Step Default Description
Operation 1=Enable
5=Disable
1=Enable Operation Off / On
Ps Seq A Hi high Lim 0.00...40.00 xIn 1.40 High alarm current limit for positive sequence current
Ps Seq A high limit 0.00...40.00 xIn 1.20 High warning current limit for positive sequence current
Ps Seq A low limit 0.00...40.00 xIn 0.00 Low warning current limit for positive sequence current
Ps Seq A low low Lim 0.00...40.00 xIn 0.00 Low alarm current limit for positive sequence current
Ps Seq A deadband 100...100000 2500 Deadband configuration value for positive sequence current for integral
calculation. (percentage of difference between min and max as 0,001%
s)
Ng Seq A Hi high Lim 0.00...40.00 xIn 0.20 High alarm current limit for negative sequence current
Ng Seq A High limit 0.00...40.00 xIn 0.05 High warning current limit for negative sequence current
Ng Seq A low limit 0.00...40.00 xIn 0.00 Low warning current limit for negative sequence current
Ng Seq A low low Lim 0.00...40.00 xIn 0.00 Low alarm current limit for negative sequence current
Ng Seq A deadband 100...100000 2500 Deadband configuration value for negative sequence current for integral
calculation. (percentage of difference between min and max as 0,001%
s)
Zro A Hi high Lim 0.00...40.00 xIn 0.20 High alarm current limit for zero sequence current
Zro A High limit 0.00...40.00 xIn 0.05 High warning current limit for zero sequence current
Zro A low limit 0.00...40.00 xIn 0.00 Low warning current limit for zero sequence current
Zro A low low Lim 0.00...40.00 xIn 0.00 Low alarm current limit for zero sequence current
Zro A deadband 100...100000 2500 Deadband configuration value for zero sequence current for integral
calculation. (percentage of difference between min and max as 0,001%
s)
